一、环境准备

1.虚拟机准备
三台openEuler系统虚拟机用于部署Ceph集群。硬件配置：2C4G，另外每台机器最少挂载三块硬盘(每块盘5G)

192.168.132.135 ceph01
192.168.132.136 ceph02
192.168.132.137 ceph03

2.在ceph三台机器操作
（1）关闭防火墙

systemctl disable --now firewalld
setenforce 0

（2）关闭selinux

sed -i 's/^SELINUX=.*/SELINUX=disabled/' /etc/selinux/config

（3）添加主机名与IP对应关系：

vim /etc/hosts
192.168.132.135 ceph01
192.168.132.136 ceph02
192.168.132.137 ceph03

（4）设置主机名：

#第一台主机
hostnamectl set-hostname ceph01
#第二台主机
hostnamectl set-hostname ceph02
#第三台主机
hostnamectl set-hostname ceph03

（5）同步网络时间和修改时区

systemctl restart chronyd.service && systemctl enable chronyd.service
cp /usr/share/zoneinfo/Asia/Shanghai /etc/localtime

（6）在ceph01实现免密登录

ssh-copy-id root@ceph02
ssh-copy-id root@ceph03

（7）每台虚拟机用 yum 命令安装isulad

yum install -y iSulad
systemctl start isulad
systemctl status isulad


[root@ceph01 ~]# isula version
Client:
  Version:      2.0.18
  Git commit:   cbbf3711bc84e5f3ef3147b4e15d85888f33cb39
  Built:        2024-03-19T12:14:14.058337789+00:00
Server:
  Version:      2.0.18
  Git commit:   cbbf3711bc84e5f3ef3147b4e15d85888f33cb39
  Built:        2024-03-19T12:14:14.058337789+00:00
OCI config:
  Version:      1.0.1
  Default file: /etc/default/isulad/config.json

（8）修改 isulad 的配置文件

[root@ceph01 ~]#  cat /etc/isulad/daemon.json
{
    "group": "isula",
    "default-runtime": "lcr",
    "graph": "/var/lib/isulad",
    "state": "/var/run/isulad",
    "engine": "lcr",
    "log-level": "ERROR",
    "pidfile": "/var/run/isulad.pid",
    "log-opts": {
        "log-file-mode": "0600",
        "log-path": "/var/lib/isulad",
        "max-file": "1",
        "max-size": "30KB"
    },
    "log-driver": "stdout",
    "container-log": {
        "driver": "json-file"
    },
    "hook-spec": "/etc/default/isulad/hooks/default.json",
    "start-timeout": "2m",
    "storage-driver": "overlay2",
    "storage-opts": [
        "overlay2.override_kernel_check=true"
    ],
    "registry-mirrors": [
        "https://gcctk8ld.mirror.aliyuncs.com"
    ],
    "insecure-registries": [],
    "pod-sandbox-image": "",
    "native.umask": "normal",
    "network-plugin": "",
    "cni-bin-dir": "",
    "cni-conf-dir": "",
    "image-layer-check": false,
    "use-decrypted-key": true,
    "insecure-skip-verify-enforce": false,
    "cri-runtimes": {
        "kata": "io.containerd.kata.v2"
    },
    "tcp-address": "0.0.0.0:2375"
}

二、开始部署

1.拉取镜像
每个虚拟机都要拉取，在此以ceph01为例

[root@ceph01 ~]# isula pull ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64
Image "ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64" pulling
Image "9a4fcaf4e9d7fcd9b9ad744b247a4d0d30a2d377d610fa8e4e42ae524d8e6b51" pulled

[root@ceph01 ~]# isula images
REPOSITORY                     TAG                                        IMAGE ID             CREATED              SIZE
ceph/daemon                    v3.0.5-stable-3.0-luminous-centos-7-x86_64 9a4fcaf4e9d7         2018-05-11 08:38:53  729.660MB

2.启动主节点mon
先在ceph01节点运行，注意MON_IP=自己机子的ip地址

[root@ceph01 ~]# isula run -d --net=host --name=mon -v /etc/ceph:/etc/ceph -v /var/lib/ceph:/var/lib/ceph -e MON_IP=192.168.132.135 -e CEPH_PUBLIC_NETWORK=192.168.132.0/24 ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64  mon
26a2c3725b8e76592dbfff66facd4fc3998d7270257da1e41f2cb5baa721bfc5
[root@ceph01 ~]# isula ps
CONTAINER ID    IMAGE                                                   COMMAND                 CREATED         STATUS          PORTS   NAMES
26a2c3725b8e    ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64  "/entrypoint.sh mon"    5 seconds ago   Up 5 seconds            mon
[root@ceph01 ~]# isula exec mon ceph -s
  cluster:
    id:     7f2fab25-e03b-4712-9728-f9a4b19ec69c
    health: HEALTH_OK

  services:
    mon: 1 daemons, quorum compute
    mgr: no daemons active
    osd: 0 osds: 0 up, 0 in

  data:
    pools:   0 pools, 0 pgs
    objects: 0 objects, 0 bytes
    usage:   0 kB used, 0 kB / 0 kB avail
    pgs:

3.拷贝配置文件和系统文件到其他两个节点

scp -r /etc/ceph ceph02:/etc/
scp -r /etc/ceph ceph03:/etc/

scp -r /var/lib/ceph ceph02:/var/lib/
scp -r /var/lib/ceph ceph03:/var/lib/

4.启动其他节点mon，对应IP做相应修改

[root@ceph02 ~]# isula run -d --net=host --name=mon -v /etc/ceph:/etc/ceph -v /var/lib/ceph:/var/lib/ceph -e MON_IP=192.168.132.136 -e CEPH_PUBLIC_NETWORK=192.168.132.0/24 ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64  mon

[root@ceph03 ~]# isula run -d --net=host --name=mon -v /etc/ceph:/etc/ceph -v /var/lib/ceph:/var/lib/ceph -e MON_IP=192.168.132.137 -e CEPH_PUBLIC_NETWORK=192.168.132.0/24 ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64  mon

5.挂载osd
注意，仔细看自己的盘是哪个，笔者的为/dev/sdc

[root@ceph01 ~]# fdisk -l
Disk /dev/sdc：5 GiB，5368709120 字节，10485760 个扇区
磁盘型号：VMware Virtual S
单元：扇区 / 1 * 512 = 512 字节
扇区大小(逻辑/物理)：512 字节 / 512 字节
I/O 大小(最小/最佳)：512 字节 / 512 字节

[root@ceph01 ~]# mkfs.xfs /dev/sdc
meta-data=/dev/sdc               isize=512    agcount=4, agsize=327680 blks
         =                       sectsz=512   attr=2, projid32bit=1
         =                       crc=1        finobt=1, sparse=1, rmapbt=0
         =                       reflink=1    bigtime=0 inobtcount=0
data     =                       bsize=4096   blocks=1310720, imaxpct=25
         =                       sunit=0      swidth=0 blks
naming   =version 2              bsize=4096   ascii-ci=0, ftype=1
log      =internal log           bsize=4096   blocks=2560, version=2
         =                       sectsz=512   sunit=0 blks, lazy-count=1
realtime =none                   extsz=4096   blocks=0, rtextents=0

[root@ceph01 ~]# mkdir /osd0
[root@ceph01 ~]# mount /dev/sdc /osd0

6.启动OSD服务

[root@ceph01 ~]#  isula run -d --net=host --name=osd1 -v /etc/ceph:/etc/ceph -v /var/lib/ceph:/var/lib/ceph -v /dev:/dev -v /osd0:/var/lib/ceph/osd --privileged=true ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64 osd_directory
cc472c45d76037d3b904de830eda2354d3d96fec9c69324869dee56597023556

[root@ceph01 ~]# isula ps
CONTAINER ID    IMAGE                                                   COMMAND                 CREATED         STATUS          PORTS   NAMES
cc472c45d760    ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64  "/entrypoint.sh os..."  4 seconds ago   Up 4 seconds            osd1
fba0bacf7517    ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64  "/entrypoint.sh mon"    2 minutes ago   Up 2 minutes            mon

7.其他节点启动OSD参考前文5和6

8.在ceph01启动mgr

[root@ceph01 ~]# isula run -d --net=host -v /etc/ceph:/etc/ceph -v /var/lib/ceph/:/var/lib/ceph/ ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64 mgr
14f678b91af65acbb3d2e1fa47e93e38c7fc98930d2d03b02c48fd9ddc195b4d


[root@ceph01 ~]# isula ps
CONTAINER ID    IMAGE                                                   COMMAND                 CREATED                STATUS                   PORTS   NAMES
80556d315be5    ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64  "/entrypoint.sh mgr"    3 seconds ago          Up 3 seconds                     80556d315be5160311c5fac8ec48ad5e76db679013a4b29d224fe3bfd8a3f5aa
cc472c45d760    ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64  "/entrypoint.sh os..."  About a minute ago     Up About a minute                osd1
fba0bacf7517    ceph/daemon:v3.0.5-stable-3.0-luminous-centos-7-x86_64  "/entrypoint.sh mon"    4 minutes ago          Up 4 minutes                     mon

[root@ceph01 ~]# isula exec mon ceph -s
  cluster:
    id:     9fbaf183-ece3-4568-801f-cb3b2a63f477
    health: HEALTH_OK

  services:
    mon: 1 daemons, quorum compute
    mgr: compute(active)
    osd: 1 osds: 1 up, 1 in

  data:
    pools:   0 pools, 0 pgs
    objects: 0 objects, 0 bytes
    usage:   242 MB used, 4867 MB / 5110 MB avail
    pgs:

9.在ceph中创建一个pool

isula exec mon ceph osd pool create rbd 64

检查osd tree

isula exec mon ceph osd tree

检查ceph运行情况

isula exec mon ceph -s
